Before Using the Machine
Xerox
®
WorkCentre
®
5022/5024 Multifunction Printer
User Guide
1-4
• The following terms are used in this guide:
- Important: Important infomation that you should read.
- Note: Additional information on operations or features.
• The following symbols are used in this guide:
• Orientation of documents or paper is described in this guide as follows:
" " : • A cross-reference included in this guide.
• Names of CD-ROM, features, and screen messages and input text.
[ ] : • Folders, files, applications, button or menu names displayed on the
screen.
• Names of menus, commands, windows, or dialog boxes displayed on
the computer screen and their buttons and menu names.
< > button : • Hardware buttons on the control panel.
< > key : • Keys on the keyboard of the computer.
> : • Path to a certain item within a procedure on the control panel.
• For example: When you see the procedure "select Tools > Default
Settings > Copy", this means that you need to select Tools, select
Default Settings, and then select Copy.
• Path to a certain item within a procedure on a computer.
• For example: When you see the procedure "to search for files and
folders, click Start > Search > For Files or Folders", this means that
you need to click Start, click Search, and then click For Files or
Folders to search for files and folders.
, ,
Long Edge Feed (LEF)
Loading the document or paper in portrait orientation when
viewed from the front of the machine.
, ,
Short Edge Feed (SEF):
Loading the document or paper in landscape orientation when
viewed from the front of the machine.
LEF Orientation SEF Orientation
Feed directionFeed direction
