Boundary-Scan for Virtex-4 Devices Using IEEE Standard 1149.1
R
Examples of how the binary digits translate into hex codes appear in Table 3-5.
Table 3-4: Virtex-4 Device JTAG ID Codes
Device IDCODE Device IDCODE Device IDCODE
XC4VLX15 01658093 XC4VFX12 01E58093
XC4VLX25 0167C093 XC4VSX25 02068093 XC4VFX20 01E64093
XC4VLX40 016A4093 XC4VSX35 02088093 XC4VFX40 01E8C093
(1)
XC4VLX60 016B4093 XC4VSX55 020B0093 XC4VFX60 01EB4093
XC4VLX80 016D8093
XC4VLX100 01700093 XC4VFX100 01EE4093
XC4VLX160 01718093 XC4VFX140 01F14093
XC4VLX200 01734093
Notes:
1. Does not reflect the actual device array size.
Table 3-5: Example JTAG IDCODE Concatenation
vvvv ffff fffa aaaa aaaa cccc cccc ccc1
XC4VLX15 bin <vvvv> 0001 0110 0101 1000 0000 1001 0011
hex <v>1658093
XC4VLX25 bin <vvvv> 0001 0110 0111 1100 0000 1001 0011
hex <v>167C093
XC4VLX40 bin <vvvv> 0001 0110 1010 0100 0000 1001 0011
hex <v>16A4093
XC4VLX60 bin <vvvv> 0000 0110 1011 0100 0000 1001 0011
hex <v>16B4093
XC4VLX80 bin <vvvv> 0001 0110 1101 1000 0000 1001 0011
hex <v>16D8093
XC4VLX100 bin <vvvv> 0001 0111 0000 0000 0000 1001 0011
hex <v>1700093
XC4VLX160 bin <vvvv> 0001 0111 0001 1000 0000 1001 0011
hex <v>1718093
XC4VLX200 bin <vvvv> 0001 0111 0011 0100 0000 1001 0011
hex <v>1734093
XC4VSX25 bin <vvvv> 0010 0000 0110 1000 0000 1001 0011
hex <v>2068093
XC4VSX35 bin <vvvv> 0010 0000 1000 1000 0000 1001 0011
hex <v>2088093
XC4VSX55 bin <vvvv> 0010 0000 1011 0000 0000 1001 0011
hex <v>20B0093
XC4VFX12 bin <vvvv> 0001 1110 0101 1000 0000 1001 0011
hex <v>1E58093
XC4VFX20 bin <vvvv> 0001 1110 0110 0100 0000 1001 0011
