Xinje XDH Series User Manual

163
Ignore the 1 of M16
Low bit coding [ENCOL]
16 bits
ENCOL
32 bits
-
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
2) Operands
Operands
Function
Data Type
S
Soft element address need coding
16bit,BIN
D
Soft element address to save coding result
16bit,BIN
n
The bit quantity of coding result
16bit,BIN
3) Suitable soft components
Operands
Word soft elements
Bit soft elements
System
Constan
t
Module
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
ID
Q
D
X
Y
M
S
T
C
Dn.
m
S
●
●
●
●
●
●
●
●
●
●
●
●
●
●
D
●
●
●
●
●
●
n
●
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD; DM
includes DM, DHM; DS includes DS, DHS. M includes M, HM, SM; S includes S, HS; T
includes T, HT; C includes C, HC.
<if is bit device > n≤16
M10ENCOL D10 K3
X0
n
S· D·
 If the number of bits in the source address is 1, the high bit side is ignored, and if the source
address is 0, the instruction will not be executed.
 When the driving condition is OFF, the instruction is not executed and the coding output is
Description
S·
