YASKAWA J1000 Technical Manual

Drive internal circuitry is worn.
• Check the maintenance time for the capacitors (U4-05).
•
Replace the drive if U4-05 exceeds 90%.
YES
The drive input power transformer is not
large enough and voltage drops when the
power is switched on.
• Check for a tripped alarm when the magnetic contactor, line breaker and leakage breaker
are turned on.
• Check the capacity of the drive input power transformer.
YES
Air inside the drive is too hot. • Check the temperature inside the drive. YES
The CHARGE indicator light is broken or
disconnected.
• Replace the drive. YES
6.5 Alarm Detection
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
143
6
Troubleshooting
http://nicontrols.com

YASKAWA J1000 Specifications

General

Series	J1000
Voltage Class	200V, 400V
Frequency	50/60 Hz
Enclosure Rating	IP20
Enclosure Type	Open type
Voltage	200-240V, 380-480V
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault, Short Circuit
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Humidity	5-95% (non-condensing)
Enclosure	IP20
Input Voltage	200-240V, 380-480V
