YASKAWA J1000 Technical Manual

Register No. Contents
002AH
Alarm Contents1
bit 0 to bit 1 Reserved
bit 2 Run Command Input Error (EF)
bit 3 Drive Baseblock (bb)
bit 4 Overtorque Detection 1 (oL3)
bit 5 Heatsink Overheat (oH)
bit 6 Overvoltage (ov)
bit 7 Undervoltage (Uv)
bit 8 Reserved
bit 9 MEMOBUS/Modbus Communication Error (CE)
bit A to F Reserved
002BH
Input Terminal Status
bit 0 Terminal S1 Closed
bit 1 Terminal S2 Closed
bit 2 Terminal S3 Closed
bit 3 Terminal S4 Closed
bit 4 Terminal S5 Closed
bit 5 to bit F Reserved
002CH
Drive Status 2
bit 0 During Run
bit 1 Zero Speed
bit 2 Speed Agree
bit 3 User Speed Agree
bit 4 Frequency Detection 1
bit 5 Frequency Detection 2
bit 6 Drive Ready
bit 7 During Undervoltage
bit 8 During Baseblock
bit 9 Frequency Reference from Operator Keypad
bit A Run Command from Operator Keypad
bit B Overtorque
bit C, D Reserved
bit E Fault
bit F Communication Timeout
002DH
Output Terminal Status
bit 0 Multi-Function Contact Output (terminal MA/MB-MC)
bit 1 to bit F Reserved
002EH to 0030H Reserved
0031H DC Bus Voltage, 1 Vdc units
0032H to 0033H Reserved
0034H
Product Code 1 [ASCII],
Product Type (J0 for J1000)
0035H to 003CH Reserved
C.10 MEMOBUS/Modbus Data Table
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
225
C
MEMOBUS/Modbus Communications
http://nicontrols.com

YASKAWA J1000 Specifications

General

Series	J1000
Voltage Class	200V, 400V
Frequency	50/60 Hz
Enclosure Rating	IP20
Enclosure Type	Open type
Voltage	200-240V, 380-480V
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault, Short Circuit
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Humidity	5-95% (non-condensing)
Enclosure	IP20
Input Voltage	200-240V, 380-480V
