Register No. Contents
003DH
Communications Error Log
<2>
bit 0 CRC Error
bit 1 Data Length Error
bit 2 Reserved
bit 3 Parity Error
bit 4 Overrun Error
bit 5 Framing Error
bit 6 Timeout
bit 7 to bit F Reserved
003EH Reserved
003FH Output Frequency 0.01% units
0040H to 007EH
Used for various monitors U1-oo. Refer to U: Monitors on page 201 for parameter details.
007FH Alarm Code, Refer to Alarm Register Contents on page 229 for alarm codes.
0080H to 0097H
Used for monitors U2-oo. Refer to U: Monitors on page 201 for parameter details and Refer to Fault History Contents on
page 229 for register value descriptions.
0098H High Word of Accumulated Operation Time Monitor (U4-01)
0099H Low Word of Accumulated Operation Time Monitor (U4-01)
009AH to 009BH Reserved
00ABH Drive Rated Current
00ACH to 00B5H Reserved
00B6H
Frequency Reference After
Soft-starter
0.01% units
00B7H Reserved
00B8H Frequency Reference 0.01% units
00B9H to 00BEH Reserved
00BFH oPE Error Number
00C0H
Fault contents 1
bit 0 Reserved
bit 1 Undervoltage (Uv1)
bit 2 Reserved
bit 3 Soft Charge Circuit Fault (Uv3)
bit 4, 5 Reserved
bit 6 Overcurrent (oC)
bit 7 Overvoltage (ov)
bit 8 Reserved
bit 9 Heatsink Overheat (oH1)
bit A Motor Overload (oL1)
bit B Drive Overload (oL2)
bit C Overtorque Detection 1 (oL3)
bit D, E Reserved
bit F Braking Resistor Overheat (rH)
00C1H
Fault contents 2
bit 0 External Fault at input terminal S3 (EF3)
bit 1 External Fault at input terminal S4 (EF4)
bit 2 External Fault at input terminal S5 (EF5)
bit 3 to 9 Reserved
bit A Input Phase Loss (PF)
bit B, C Reserved
bit D Digital Operator Connection Fault (oPr)
bit E EEPROM Write Error (Err)
bit F Reserved
C.10 MEMOBUS/Modbus Data Table
226
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
