YASKAWA J1000 Technical Manual

Register No. Contents
00C2H
Fault contents 3
bit 0 MEMOBUS/Modbus Communication Error (CE)
bit 1 to 5 Reserved
bit 6
External fault (EF0) is detected in RS-422/RS-485 Interface for MEMOBUS/Modbus
Communication
bit 7 to E Reserved
bit F Hardware fault (includes oFx)
00C3H Reserved
00C4H
Fault contents 5
bit 0 Reserved
bit 1 External Fault 1, input terminal S1 (EF1)
bit 2 External Fault 2, input terminal S2 (EF2)
bit 3, 4 Reserved
bit 5 Current Offset Fault (CoF)
bit 6 to F Reserved
00C5H to 00C7H Reserved
00C8H
Alarm contents 2
bit 0 Undervoltage (Uv)
bit 1 Overvoltage (ov)
bit 2 Heatsink Overheat (oH)
bit 3 Reserved
bit 4 Overtorque 1 (oL3)
bit 5 Reserved
bit 6 Run Commands Input Error (EF)
bit 7 Drive Baseblock (bb)
bit 8 External Fault 3, input terminal S3 (EF3)
bit 9 External Fault 4, input terminal S4 (EF4)
bit A External Fault 5, input terminal S5 (EF5)
bit B to F Reserved
00C9H
Alarm contents 3
bit 0, 1 Reserved
bit 2 Digital Operator Connection Fault (oPr)
bit 3 MEMOBUS/Modbus Communication Error (CE)
bit 4 Reserved
bit 5 Serial Communication Transmission Error (CALL)
bit 6 Motor Overload (oL1)
bit 7 Drive Overload (oL2)
bit 8 to F Reserved
00CBH
Alarm contents 5
bit 0 to 7 Reserved
bit 8 External Fault 1 (input terminal S1) (EF1)
bit 9 External Fault 2 (input terminal S2) (EF2)
bit A to F Reserved
00CCH-00CFH Reserved
C.10 MEMOBUS/Modbus Data Table
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
227
C
MEMOBUS/Modbus Communications
http://nicontrols.com

YASKAWA J1000 Specifications

General

Series	J1000
Voltage Class	200V, 400V
Frequency	50/60 Hz
Enclosure Rating	IP20
Enclosure Type	Open type
Voltage	200-240V, 380-480V
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault, Short Circuit
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Humidity	5-95% (non-condensing)
Enclosure	IP20
Input Voltage	200-240V, 380-480V
