YASKAWA NX100 Maintenance Manual

10.3 7 SEG-LED Indicator
10-5
AXA01/AXA02
All Lit The power has been turned ON.
0 The booting program has started. (ROM/RAM/FP register check)
1 Starts the booting system. (Completes initializations of various kinds.)
2 Completes the preparation for receiving the system program.
3 The system program has been received. (Waits for the request of system change.)
4 The system program has started. (Starts up hardware initializations of various kinds.)
5 Starts the system. (Completes initializations of various kinds.)
6 Starts the CMOS data transmission.
7 Receives the CERF mapping. (Waits for pre-online)
8 Starts the servo system. (Starts the process of various initializations.)
9 Waits for CERF communication synchronization. (Completes the process of various ini-
tializations.)
A
B Waits for the start-up of on-line system.
C
D Completes the NX setup process. (Servo ON enabled)
NCP02
All Lit The power has been turned ON.
0 The booting program has started. (ROM/RAM/FP register check)
1 Starts the booting system. (Completes initializations of various kinds.)
2 Completes the preparation for receiving the system program.
3 The system program has been received. (Waits for the request of system change.)
4 The system program has started. (Starts up hardware initializations of various kinds.)
5 Starts the system. (Completes initializations of various kinds.)
6 Starts the CMOS data transmission.
7 Receives the CERF mapping. (Waits for pre-online)
8 Starts the optional system. (Starts the process of various initializations.)
9
A
B
C
D Completes the NX setup process.

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
