YASKAWA NX100 - 7 SEG-LED Indicator Status (1-digit indication) of Each Unit at Error Occurrence

10.3 7 SEG-LED Indicator
10-4
 7 SEG-LED Indicator Status (1-digit indication) of Each Unit
at Error Occurrence
NIF01
All Lit The power has been turned ON.
0 The booting program has started.
1 The system program has started. (Starts up initializations of various kinds.)
2 Starts verifying the existence of other circuit boards. (Verifies the start-up of the booting
program.)
3 Starts the system program transmission.
4 Sends the request of the system program start-up.
5 Starts verifying the existence of other circuit boards. (Verifies the start-up of the system
program.)
6 Acquires hardware information, etc. of other circuit boards. (Verifies the IO board status,
servo IF, and so on.)
7 Starts the CMOS data transmission.
8 Sends the pre-online request.
9 Waits for CERF communication synchronization.
A
B Sends the start-up request of on-line system.
C The on-line system has started. (Starts up the initialization task.)
D Processes the NX100 setup completion. (Servo ON enabled)
E Alarm occurs at the NX100 setup.
F The maintenance system is starting up.
P Communications interrupted between NCP01 and the programming pendant.
U Updating system software through network.
