5.2 NX100 Parts List
5-15
5.2 NX100 Parts List
*1 The type of the SERVOPACK depends on the manipulator model. For details, see the
table "SERVOPACK List."
*2 The type of the power supply contactor unit depends on the manipulator model. For
details, see the table "Power Supply Contactor Unit List."
NX100 Parts List
No. Name Model Comment
1SERVOPACK
*1
6 axes type
2 CPU unit JZNC-NRK01
Backboard JANCD-NBB01
Control circuit board JANCD-NCP01
Servo control circuit board SGDR-AXA01A Not included in CPU unit
(JZNC-NRK01)
Control power supply CPS-420F Not included in CPU unit
(JZNC-NRK01)
Robot I/F unit JZNC-NIF01 Not included in CPU unit
(JZNC-NRK01)
Robot I/F circuit board JANCD-NIF01
I/O circuit board JANCD-NIO01
3 Power supply contactor unit
*2
4
Interior circulation fan
4715MS-22T-B50-B00
5 Backside duct fan 4715MS-22T-B50-B00 HP3, HP6, EA1400N,
HP20, EA1900N
5915PC-22T-B30-B00 UP50N, UP20MN,
ES165N, HP165,
ES200N, ES165RN,
ES200RN
6 Power supply contactor unit fuse 326010, 10A, 250V Time lag fuse
SDP50, 5A, 125V Alarm fuse
Robot I/F unit fuse 2173.15P, 3.15A, 250V Rapid cut fuse
7 Battery ER6VC3N 3.6V
8 Welder I/F board JANCD-XEW02 Only for arc welding
Welder I/F board fuse 0312001.MXP, 1A, 250V Fast-acting fuse, only for
arc welding
To Next Page
