YASKAWA NX100 Maintenance Manual

7.3 Input/Output Status
7-12
7.3.7 Relay Number Search
A search can be made for a relay number of a universal input, universal output, specific input,
and specific output.
A search for the relay number can be made in the following two ways.
• Direct search on the UNIVERSAL/SPECIFIED INPUT/OUTPUT window
• Search from the menu
IG#01
123 : 10
7b : 16
DATA
EDIT
DISPLAY
UTILITY
Main Menu Short Cut
T
PAGE
UNIVERSAL INPUT
GROUP
IG#001
0:DEC. 00:HEX.








IN#0001 #00010
IN#0002 #00011
IN#0003 #00012
IN#0004 #00013
IN#0005 #00014
IN#0006 #00015
IN#0007 #00016
IN#0008 #00017
Relay No.
Relay No.

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
