7.3 Input/Output Status
7-15
7.3.8 Modification of the Signal Name
The name of the universal input or output signal can be modified.
The name can be modified in the following two ways.
• Direct modification on the
UNIVERSAL/SPECIFIED INPUT/OUTPUT window.
• Modification from the menu
Direct Modification on the Universal/Specified Input/Output Window
Operation Explanation
1 Move the cursor to the signal
name to be modified in the
UNIVERSAL/SPECIFIED
INPUT/OUTPUT window,
and press [SELECT].
The window for character input appears.
2 Enter the signal name.
3 Press [ENTER]. New signal name is registered.
IG#01
123 : 10
7b : 16
DATA
EDIT
DISPLAY
UTILITY
Main Menu ShortCut
T
PAGE
UNIVERSAL INPUT
GROUP
IG#001
0:DEC. 00:HEX.
IN#0001 #00010
IN#0002 #00011
IN#0003 #00012
IN#0004 #00013
IN#0005 #00014
IN#0006 #00015
IN#0007 #00016
IN#0008 #00017
Signal name
IG#01
123 : 10
7b : 16
DATA
EDIT
DISPLAY
UTILITY
Main Menu
Short Cut
T
PAGE
UNIVERSAL INPUT
GROUP
IG#001
0:DEC. 00:HEX.
IN#0001 #00010
IN#0002 #00011
IN#0003 #00012
IN#0004 #00013
IN#0005 #00014
IN#0006 #00015
IN#0007 #00016
IN#0008 #00017
TEST SIGNAL
