YASKAWA NX100 Maintenance Manual

4.1 Creating a Check Program
4-3
4.1 Creating a Check Program
To check position deviation whenever necessary, create a program in which a check point is
taught (the job for the check point). In the job for the check point, teach two points; one as a
check point and the other as the point to approach the check point. This program checks for
any deviation between the tool tip position and the check point.
Enlarged View

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
