YOKOGAWA µR1800 User Manual

10 - 1
IM 4H3B1-01E
1
0. GENERAL SPECIFICATIONS
Chapter 10 GENERAL SPECIFICATIONS
MODELS 1, 2, 3 and 4 pen; 6 dot, 12 dot, 18dot and 24 dot printing model
TYPES DCV : Direct Voltage input 20mV to 20V range.
TC : Thermocouple.
RTD : Resistance Temperature Detector.
DI : Digital Input (contact or DC Voltage, TTL level).
DCA : Direct Current Input (using external shunt resistor (10Ω, 100Ω, 250Ω)).
Measuring Range: selectable per channel
*1 R, S, B, K, E, J, T: ANSI, IEC 584, DIN IEC 584, JIS C 1602-1981
*2 N: Nicrosil-Nisil, IEC 584, DIN IEC 584
*3 W: W·5%Re / W·26%Re (Hoskins Mfg. Co.)
*4 L: Fe-CuNi, DIN 43710 U: Cu-CuNi, DIN 43710
*5 PT100: JIS C 1604-1989, JIS C 1606-1989, IEC 751, DIN IEC 751
JPT100: JIS C 1604-1981, JIS C 1606-1989
Input Type Range
Measuring Range
DCV 20mV –20.00 to 20.00mV
60mV –60.00 to 60.00mV
200mV –200.0 to 200.0mV
2V –2.000 to 2.000V
6V –6.000 to 6.000V
20V –20.00 to 20.00V
TC
R
0.0 to 1760.0°C
Range Measuring Range °C Measuring Range °F
32 to 3200°F
S 0.0 to 1760.0°C 32 to 3200°F
B 0.0 to 1820.0°C 32 to 3308°F
K –200.0 to 1370.0°C –328 to 2498°F
E
–200.0 to 800.0°C –328.0 to 1472.0°F
J
–200.0 to 1100.0°C –328.0 to 2012.0°F
T
–200.0 to 400.0°C –328.0 to 752.0°F
N
0.0 to 1300.0°C 32 to 2372°F
W
0.0 to 2315.0°C
32 to 4199°F
L
–200.0 to 900.0°C
–328.0 to 1652.0°F
U
–200.0 to 400.0°C
–328.0 to 752.0°F
RTD Range Measuring Range °C Measuring Range °F
PT100
–200.0 to 600.0°C
–328.0 to 1112.0°F
JPT100
–200.0 to 550.0°C
–328.0 to 1022.0°F
DI Range Measuring Range
Voltage input
less than 2.4V is OFF, more than 2.4V is ON(TTL)
(Digital Input)
Contact input
contact ON/OFF
*1
*1
*1
*1
*1
*1
*1
*2
*3
*4
*4
*5
*5
PLT
0.0 to 1400.0°C
32 to 2552.0°F
PR
0.0 to 1900.0°C
32 to 3452.0°F
JP50
–200.0 to 600.0°C
–328.0 to 1112.0°F
CU1 to 6 (Cu10)
–200.0 to 300.0°C
–328.0 to 572.0°F
CU25 (Cu25)
–200.0 to 300.0°C
–328.0 to 572.0°F
