2.2 Checking the Contents
This µR1800 was thoroughly inspected before it was shipped from the factory.
However, when you receive the µR1800, check that all accessories are present and in
the correct quantities. Also check the external appearance of the µR1800 to ascertain
that no damage has occurred.
2.2.1 Checking Accessories and Appearance
The µR1800 should be accompanied by the accessories indicated in figure 2.1.
Check that all are present in the correct quantities. Also check the external appearance
of the µR1800 to ascertain that no damage has occurred. If you discover any problem
concerning the quantity of accessories or external appearance, please contact your sales
representative or the nearest service center. Addresses may be found on the back cover
of this Instruction Manual.
1
2
3 4 5 6 7 8
No. Description Quantity Remarks
1.
disposable felt pen (for pen model)
• 1 pen model
• 2 pen model
• 3 pen model
• 4 pen model
plotter pen (for pen model)
ribbon cassette (for dot model)
fuse
key
mounting brackets
Z-fold chart paper
Instruction Manual and Quick
Reference power cord
1
2
3
4
1
1
1
1
1
1
2
2
1
1
1
red
red, green
red, green, blue
red, green, blue, violet
purple
250V 750mA time lag
(except for /P1 model)
250V 5A time lag
(for /P1 model)
Recorders with a gray power switch
250V 800mA time lag
(except for /P1 model)
250V 5A time lag
(for /P1 model)
Recorders with a white power switch
key-lock
approx. 20 meters
one each
for portable type
2.
3.
4.
5.
6.
7.
8.
Figure 2.1 Accessories
Z-fold chart paper
disposable felt-pen
disposable felt-pen
disposable felt-pen
disposable felt-pen
plotter pen
ribbon cassette
fuse
mounting brackets
key (for key-lock)
lubricating oil
B9573AN
B9902AM
B9902AN
B9902AP
B9902AQ
B9902AR
B9906JA
A1438EF
A1102EF
A1512EF
A1513EF
B9900CW
B9900HZ
B9901AZ
(1 chart/unit), order quantity: 6 units
red (3 pcs./unit), order quantity: 1 unit
green (3 pcs./unit), order quantity: 1 unit
blue (3 pcs./unit), order quantity: 1 unit
violet (3 pcs./unit), order quantity: 1 unit
(3 pcs./unit), order quantity: 1 unit
(1 pc./unit), order quantity: 1 unit
(4pcs./unit), order quantity : 1 unit
250V 750mA time lag
(except for /P1 model)
(4pcs. /unit), order quantity : 1 unit
250V 5A time lag
(for /P1 model)
Recorders with a gray power switch
(4pcs. /unit), order quantity : 1 unit
250V 800mA time lag
(except for /P1 model)
(4pcs. /unit), order quantity : 1 unit
250V 5A time lag
(for /P1 model)
Recorders with a white power switch
(1 pc./unit), order quantity: 2 units
(1 pc./unit), order quantity: 2 units
(1 pc./unit), order quantity: 1 unit
Name Part Number Description
Table 2.1 Spares
To Next Page
