13185L-002 Rev. A 1/24/06 110XiIIIPlus Maintenance Manual Page 3-15
Troubleshooting Section 3
Printer stops and
PAUSE LED lights. LCD
displays:
Not enough memory to
perform the function indicated
in the second line of the
display. (Printer may not be
configured for continuous
label stock with the maximum
label length set too long.)
Functions:
1. Creating a bitmap size is
larger than label length/
width specified.
2. Storing a bitmap: Not
enough memory available
to store bitmap created.
3. Building a format: Label is
too complex.
4. Storing a format size too
large to fit in available
memory.
5. Storing a graphic image is
too large to fit in available
memory.
6. Storing a font: Not enough
memory to store font.
You may do any of the
following:
7. Storing errors: With
PAUSE on, use the ~HM
ZPL II command to display
the amount of memory
available. Redesign
graphic/format to fit in
available memory or
remove items from
memory to create more
space.
or
8. Press PAUSE to skip that
step in the process and
continue to the next step.
9. With Pause on, press
CANCEL— printer skips
that label formatting
process and continues to
the next label format.
10. Turn printer Off (O) to clear
printer memory and start
over.
Poor print quality. Darkness set too low. Reconfigure darkness setting.
Incorrect media and ribbon. Replace media and ribbon.
Printhead just replaced. Ensure printhead is installed
properly with no wires or
debris caught underneath.
Incorrect printhead
adjustments.
Perform required adjustments.
Printhead resistance not
configured to proper value.
Reconfigure printhead
resistance.
Truncated print, no print,
or FEED operates
incorrectly while using
non-continuous media.
Maximum label length
parameter set less than actual
label length.
Set correct label length.
Printer in Rewind or Peel-Off
Mode turned on without media
or liner around rewind spindle.
Load media correctly for
Rewind or Peel-Off Mode.
Long vertical tracks of
missing print on several
labels.
Wrinkled ribbon. Refer to Wrinkle Ribbon
Symptom on page 3-16 of this
table.
Print element damaged. Replace printhead.
Table 3-3. Basic Troubleshooting (Continued)
Symptom Diagnosis Action
ERR0R CONDITION
Out of Memory
To Next Page
