Page 4-104 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 4 Maintenance
Table 4-4. Twinax Interface Board DIP Switch Settings
Print Complete
Switch #1 Description
Left An Operation Complete status message is sent to the host after a label
format is completely printed. The host can then send the next label
format to be printed.
Right Enables the Early Print Complete function. The host can send additional
print jobs to the Zebra printer without waiting for the actual completion of
the current print job. The printing status sent to the host reflects the label
formats received, not the ones completed.
EBCDIC Buffer Print
Switch #2 Description
Left Normal operation (received EBCDIC data is translated to ASCII Data).
Right Received EBCDIC data print as large characters that are readable hex
equivalents. Use only for troubleshooting the printer in Diagnostic Mode.
Printer Emulation Selections
Switch #3 Switch #4 IBM Printer Configured
Left Left 5256 Model 3
Left Right 5225 Model 4
Right Left 5224 Model 2
Right Right 4212 Model 2
Default Language Selections
Switch #5 Switch #6 Switch #7 Switch #8 Language Selected
Left Left Left Left 0—Multinational
Left Left Left Right 1—USA/Canada (Factory setting)
Left Left Right Left 2—Austria/Germany
Left Left Right Right 3—Belgium
Left Right Left Left 4—Brazil
Left Right Left Right 5—Canada (French)
Left Right Right Left 6—Denmark/Norway
Left Right Right Right 7—Finland/Sweden
Right Left Left Left 8—France
Right Left Left Right 9—Italy
Right Left Right Left A—Japan
Right Left Right Right B—Japan (English)
Right Right Left Left C—Portugal
Right Right Left Right D—Spain
Right Right Right Left E—Spanish-Speaking
Right Right Right Right F—United Kingdom
Note • The language character sets 1 — US/Canada and B — Japan (English)
are the same. The character sets for D — Spain and E — Spanish-Speaking are
the same.
