13185L-002 Rev. A 1/24/06 110XiIIIPlus Maintenance Manual Page 4-123
Maintenance Section 4
Figure 4-84. Install the Printhead Test Board
4. Refer to Figure 4-85. Cut and discard the cable ties and unplug the printhead power
cable from the power supply (J3).
Printhead
Test Board
Mounting
Screws
Note • Make a note of all the wires and locations of the cable ties; you will have
to replace them later.
