8 Operation Instructions for Use
2660021169042 Rev. A 2018-038.5 Acquire Data (Scan)
94 / 246 2660021169042 Rev. A 2018-03
1
2
3
4
7
5 6
ð The chinrest moves into place for the selected scan.
3. To change the FOV, click the FOV (2) appropriate for the
patient.
4. Left-click on the center of the pupil (3) in the viewport (4).
ð The pupil target appears in the viewport.
5. If needed, move the chinrest settings (5) to position the
image in the viewport (4).
6. Click Auto Focus (6) and ensure that the pupil target (3)
remains centered.
NOTE
If the fundus image becomes dark after you click Auto Focus,
recenter the pupil target and adjust the image brightness.
7. Click Optimize (7).
