8. The Menu
87
You interpret the LEDs as follows:
a. LED on Call 1 indicates the status of the PC circuit.
b. LED on Call 2 indicates the status of the LAN circuit.
TFTP Address. This is what has been configured manually or obtained by DHCP. If the DHCP
server did not specify the TFTP address, the phone indicates this:
Configuration File. Once the phone obtains the address of the TFTP server, it tries to retrieve its
configuration file from the TFTP server. It reports whether the file was read correctly or not:
8.3.3 Manufacture
When you select Menu | Information | Manufacture, the phone shows the following displays.
You can only view this information. Use the Up and Down keys to scroll through the various
screens. The display on your phone may differ from the screens shown below.
MAC Address. This is hard coded into the phone during manufacture and cannot be modified.
1
Info | Comms
}TFTP Address
192.168.1.100
Info | Comms
}TFTP Address
not found
Info | Comms
}Config file
OK
Info | Comms
}Config file
not found
Info | Manfr
}MAC address
000BEA801B0F
1. The MAC address uniquely identifies your phone. The MAC address is printed on a label on the base of the phone as a
bar code with text.
