8. The Menu
113
To access this panel, select Menu | Pswd Settings | SIP Settings | SIP Validation.
8.5.4 VLAN
You configure VLANs on the switch that is built into the phone to match your network, optimize
performance, and obtain the best speech quality. You must enter the password prior to modifying
the VLAN configuration.
You can have one to eight VLANs on the phone. These are referred to as A, B, C, D, E, F, G, and
H. For each VLAN, you can specify the VLAN ID from 1 to 4095.
Each Ethernet circuit can be on different VLANs. The phone itself is considered to connect to a
separate Ethernet circuit on the switch, as shown in figure 1-3 on page 4.
To configure the VLANs, do the following:
1. If you have not already done so, enter the password as described in section 8.5.1 on page 103
so that you have rights to make the changes.
2. Select VLAN from the menu (Menu | Pswd Settings | VLAN).
The display shows:
Select On to enable VLAN support.
3. Press the enter button. The display shows:
Type a number from 1 to 4095. Use the Up and Down keys and the keypad to edit the ID
number. The default value is 1.
4. Press the OK button. The phone changes the display to:
Type a number from 1 to 4095 or press *. When you press * the phone clears the number and
indicates that this VLAN definition is not used. This is the default value.
Validate request
URI in SIP msgs?
}No Yes
VLAN support
}No Yes
VLAN definition
A: 1
(1 to 4095)
VLAN definition
B: * not used *
(1 to 4095;*=no)
