Zurich ZR15 User Manual

Table of Contents
i
SAFETY PRECAUTIONS
IMPORTANT SAFETY INFORMATION .......................................... 1
SCAN TOOL CONTROLS
CONTROLS AND INDICATORS ..................................................... 2
DISPLAY FUNCTIONS .................................................................... 3
BATTERY REPLACEMENT ............................................................. 5
USING THE SCAN TOOL
CODE RETRIEVAL PROCEDURE .................................................. 6
THE SYSTEM MENU ........................................................................ 11
VIEWING OEM ENHANCED DTCs (except Ford/Mazda) .............. 11
VIEWING OEM ENHANCED DTCs (Ford/Mazda only) .................. 12
VIEWING ABS DTCs ........................................................................ 14
VIEWING SRS DTCs ....................................................................... 15
NETWORK TEST ............................................................................. 16
ERASING DIAGNOSTIC TROUBLE CODES (DTCs) .................... 19
LIVE DATA MODE
VIEWING LIVE DATA ....................................................................... 21
CUSTOMIZING LIVE DATA (PIDs) ................................................. 22
RECORDING (CAPTURING) LIVE DATA ........................................ 23
LIVE DATA PLAYBACK ................................................................... 26
ADDITIONAL TESTS
THE MAIN MENU .............................................................................. 28
SYSTEM/ACTUATOR TESTS ......................................................... 28
SYSTEM TEST MENU ..................................................................... 77
VIEWING VEHICLE INFORMATION ............................................... 80
RESETTING THE OIL MAINTENANCE LIGHT .............................. 81
USING THE DLC LOCATOR ........................................................... 83
BATTERY RESET ............................................................................ 83
BATTERY/ALTERNATOR MONITOR ............................................. 85
VIEWING DRIVE CYCLE PROCEDURES ...................................... 88
STEERING ANGLE SENSOR (SAS) CALIBRATION ..................... 89
VIEWING THE FIRMWARE VERSION ........................................... 90
THE TOOL LIBRARY ....................................................................... 90
ADJUSTMENTS, SETTINGS AND LANGUAGE ............................ 93
OBD UPDATER ................................................................................ 95
USING SCAN TOOL MEMORY
VIEWING DATA IN MEMORY ......................................................... 96
TROUBLESHOOTING
TROUBLESHOOTING ................................................................... 97
WARRANTY AND SERVICING
LIMITED 90 DAY WARRANTY ......................................................... 97
SERVICE PROCEDURES ............................................................... 98

Zurich ZR15 Specifications

General

Live Data	Yes
Code Definitions	Yes
Graphing	Yes
Battery Voltage Check	Yes
Internet Updateable	Yes
Display	2.8-inch color LCD
OBDII Protocols	J1850 VPW, J1850 PWM, ISO9141
Functions	Read and clear codes, live data, freeze frame, I/M readiness, O2 sensor test, onboard monitor test, vehicle information
Multilingual Support	English, Spanish, French
