Zurich ZR15 User Manual

Additional Tests
SYSTEM/ACTUATOR TESTS
For technical questions, please call 1-888-866-5797. 45
n A “status” screen displays while a vehicle status check is
performed.
3. A “confirmation” screen displays when the routine begins.
n A “results” screen displays when the routine has completed.
4. Choose Finish to return to the Special Functions menu.
Reverse Brake Torque Test
1. Select Reverse Brake Torque Test in the Special Functions menu,
then press ENTER .
n An “instructional” screen displays. Prepare the vehicle for test as
directed:
- Start and idle the engine.
- Make sure transmission fluid temperature is 27°C (80°F) minimum
- Set the parking brake.
- Press and hold the brake pedal.
- Place the transmission in REVERSE.
2. Choose Yes to continue.
n A “status” screen displays while a vehicle status check is
performed.
3. A “confirmation” screen displays when
the test routine begins.
n A “results” screen displays when the
test has completed.
n The screen shows the current
Engine Speed, Turbine Speed and
Output Speed, the Throttle
Position Sensor Voltage an the
Present Gear.
4. Choose Finish to return to the Special Functions menu.
PTO & Idle Up
The PTO & Idle Up function lets you perform a Power Take-Off (PTO)
and Idle Up test.
1. Select PTO & Idle Up in the Special Functions menu, then press
ENTER .
n An “instructional” screen displays. Prepare the vehicle for test as
directed:
- Turn the ignition on. DO NOT start the engine.
2. Choose Yes to continue.

Zurich ZR15 Specifications

General

Live Data	Yes
Code Definitions	Yes
Graphing	Yes
Battery Voltage Check	Yes
Internet Updateable	Yes
Display	2.8-inch color LCD
OBDII Protocols	J1850 VPW, J1850 PWM, ISO9141
Functions	Read and clear codes, live data, freeze frame, I/M readiness, O2 sensor test, onboard monitor test, vehicle information
Multilingual Support	English, Spanish, French
