Additional Tests
SYSTEM/ACTUATOR TESTS
38 For technical questions, please call 1-888-866-5797.
n An “instructional” screen displays. Prepare the vehicle for test as
directed:
- Turn the ignition on. DO NOT start the engine.
2. Choose Yes to continue.
n A “status” screen displays while a vehicle status check is
performed.
3. A “confirmation” screen displays when
the test routine begins.
n A “results” screen displays when the
test procedure has completed.
n The screen shows the current values
for APP 1 Volts, APP 2 Volts, TPS
1 Volts, TPS 2 Volts and Throttle
Blade 1 Position.
4. Choose Finish to return to the Special
Functions menu.
Pedal Follower Mode
1. Select Pedal Follower Mode in the Special Functions menu, then
press ENTER .
n An “instructional” screen displays. Prepare the vehicle for test as
directed:
- Turn the ignition on. DO NOT start the engine.
2. Choose Yes to continue.
n A “status” screen displays while a vehicle status check is
performed.
3. A “confirmation” screen displays when
the test routine begins.
n A “results” screen displays when the
test procedure has completed.
n The screen shows the current values
for APP 1 Volts, APP 2 Volts, TPS
1 Volts, TPS 2 Volts and Throttle
Blade 1 Position.
4. Choose Finish to return to the Special Functions menu.
NVLD Forced Monitor Test Routine Start
The NVLD Forced Monitor Test Routine Start function lets you perform a
Natural Vacuum Leak Detection (NVLD) forced monitor test.
1. Select NVLD Forced Monitor Test Routine Start in the Special
Functions menu, then press ENTER .

Zurich ZR15 Specifications

General

Live Data	Yes
Code Definitions	Yes
Graphing	Yes
Battery Voltage Check	Yes
Internet Updateable	Yes
Display	2.8-inch color LCD
OBDII Protocols	J1850 VPW, J1850 PWM, ISO9141
Functions	Read and clear codes, live data, freeze frame, I/M readiness, O2 sensor test, onboard monitor test, vehicle information
Multilingual Support	English, Spanish, French
