VIEWING DATA IN MEMORY
96 For technical questions, please call 1-888-866-5797.
When you retrieve DTCs from a vehicle, the data is saved to the Scan
Tool’s memory. The Scan Tool stores data for the three most recent
vehicle’s tested.
Each time you retrieve DTCs from a new vehicle, existing data
for the oldest vehicle in the Scan Tool's memory is overwritten
with the new data.
VIEWING DATA IN MEMORY
When you turn the Scan Tool on while NOT connected to a vehicle, and
data is currently saved in the Scan Tool’s memory, the Scan Tool enters
Memory mode. You can view DTCs and Live Data stored in the Scan
Tool’s memory.
1. With the Scan Tool NOT connected to a vehicle, press and release
POWER/LINK to turn the Scan Tool on.
n If the Scan Tool’s batteries are low,
a warning message displays.
Replace the batteries before con-
tinuing.
2. If more than one vehicle is stored in the
Scan Tool’s memory, the Vehicle
Selection menu displays. Select the
desired vehicle, then press ENTER .
If there are no vehicles
currently stored in the
Scan Tool, an advisory
message displays.
Press M to return to the
Main Menu.
n The Memory System Menu
displays.
3. Select the DTCs you wish to view,
then press ENTER .
n The Scan Tool displays the "priority" DTC.
If there are no DTCs currently stored in the Scan Tool’s
memory, an advisory message shows on the display.
n Press DTC/FF
to scroll through all stored DTCs, and to view
Freeze Frame data for the priority DTC.
n When all DTCs have been displayed and DTC/FF
is pressed, the
Scan Tool displays the first enhanced DTC stored in memory. Press
DTC/FF
to scroll through all stored enhanced DTCs.
n Choose FixAssist to view FixAssist information for the “priority”
DTC.
n Choose Freeze Frame to view Freeze Frame data for the “priority”
DTC.
4. When you have finished viewing data in the Scan Tool's memory,
press and release POWER/LINK to turn the Scan Tool off.
