Zurich ZR15 User Manual

Additional Tests
SYSTEM/ACTUATOR TESTS
40 For technical questions, please call 1-888-866-5797.
Set Engine RPM
The Set Engine RPM function lets you set engine speed to a specified
value.
1. Select Set Engine RPM in the Special Functions menu, then press
ENTER .
n An “instructional” screen displays. Prepare the vehicle for test as
directed:
- Start and idle the engine.
2. Choose Yes to continue.
n A “status” screen displays while a vehicle status check is
performed.
n The Select RPM screen displays.
3. Select the desired RPM value (700 RPM to 1300 RPM), as desired,
then press ENTER .
n The Test Results screen displays.
n The screen shows the current
Engine Speed.
4. If desired, choose Reselect to return to
the Select RPM screen, and repeat step
3 to select a new engine speed.
5. Choose Finish to return to the Special
Functions menu.
Set RPM Test
The Set RPM Test lets you set engine speed to a specified value.
1. Select Set Engine RPM in the Special Functions menu, then press
ENTER .
n An “instructional” screen displays. Prepare the vehicle for test as
directed:
- Start and idle the engine.
2. Choose Yes to continue.
n A “status” screen displays while a
vehicle status check is performed.
n The Select RPM screen displays.
3. Select the desired RPM value (Idle to
1500 RPM), as desired, then press
ENTER .
n The Test Results screen displays.

Zurich ZR15 Specifications

General

Live Data	Yes
Code Definitions	Yes
Graphing	Yes
Battery Voltage Check	Yes
Internet Updateable	Yes
Display	2.8-inch color LCD
OBDII Protocols	J1850 VPW, J1850 PWM, ISO9141
Functions	Read and clear codes, live data, freeze frame, I/M readiness, O2 sensor test, onboard monitor test, vehicle information
Multilingual Support	English, Spanish, French
