106 ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A
Delete measuring range
NOTICE
Deleting measuring ranges is only possible with the analyzer module FID.
Menu path
MENU → Configure → Component-specific → Measuring Range
(→ Select component) → ...
Selection
Displayed are all measuring ranges configured (at the plant) for a measured
component.
If a measuring range can be deleted from the configuration of the measured
components the DEL. RANGE softkey is displayed.
NOTICE
The deleting of measuring ranges can be locked when configuring the ana-
lyzer module using TCT.
The active measuring range (in which the measuring is currently being car-
ried out) as well as the measuring ranges of the adjustment method cur-
rently active cannot be deleted.
Procedure
1 Press DEL. RANGE softkey.
2 Confirm the safety query by pressing DEL. RANGE softkey where
applicable, enter password (level 1).
The "Free" entry is displayed in the list instead of the measuring range
deleted.
