ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A 105
Add measuring range
NOTICE
Adding measuring ranges is only possible with the analyzer module FID.
Menu path
MENU → Configure → Component-specific → Measuring Range
(→ Select component) → ...
Selection
Displayed are all measuring ranges configured (at the plant) for a measured
component.
If the entry "Free" appears in the list, a measuring range can be added to the
configuration of the measured component. To this end, the NEW RANGE
softkey is displayed.
NOTICE
If the adding of measuring ranges for the configuration of the analyzer
module was blocked with TCT, the "Free" entry does not appear, even if few-
er than the 4 maximum measuring ranges possible are displayed.
Procedure
1 Press NEW RANGE.
2 Confirm the safety query by pressing NEW RANGE, where applicable,
enter password (level 1).
Instead of the "Free" entry, a new measuring range is displayed in the
list.
3 If necessary, by pressing CHANGE LIMIT, call up the menu for changing
the measuring range limits (see page 103) and change the limits of the
measuring range added.
4 If necessary, by pressing DECIMAL PLACES, call up the menu for
changing the decimal places (see page 104) and change the number of
decimal places of the measuring range added.
