ABB ACF5000 User Manual

182 ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A
No. Text S A
W
F Reaction/Comment
311 The pressure regulator works
erroneously.
x x see status message of the relevant pressure detector
312 The pressure correction for this
component was deactivated
because the pressure measured
value is invalid.
x see status message of the relevant pressure detector
313 No excess sensitivity correction
for this component is possible,
as the correction value is inva-
lid.
x see status message of the relevant correction detector
314 No carrier gas correction for
this component is possible, as
the correction value is invalid.
x see status message of the relevant correction detector
Auxiliary detector
315 No new measured values from
the analog/digital converter.
x Notify service.
316 The measured value exceeds
the value range of the ana-
log/digital converter.
x Notify service.
317 A calculation error occurred
while calculating the measured
value.
x Notify service.
FID
321 The temperature of the detec-
tor falls below the minimum
temperature.
x x Status message during the warm-up phase. If the status
message occurs after the warm-up phase: check fuse
and replace, if necessary.
322 The flame is off. x x Status message during the warm-up phase. If the status
message occurs after the warm-up phase: check supply
gases, check glow plug.
323 The analyzer is in
fail-safe mode.
x x Causes: flame temperature > Detector set point + 220°C,
hardware errors, Pt100 line break or short-circuit.
Switch power supply off and back on after ≥ 3 seconds.
If the status message recurs, notify service.
Note: Fail-safe means: heater off, combustion gas valve
closed, instrument air valve closed, housing purging on,
zero gas valve open.
Temperature controller
324 The temperature exceeds or
falls below the top or bottom
limit value 1.
x Status messages during the warm-up phase.
If status messages occur after the warm-up phase:
check whether the permissible ambient temperature
range (see page 191) is observed.
FID: The temperatures of the detector (T-Re.D) and,
where applicable, of the heated measuring gas connec-
tion (T-Re.E) are outside the limit values.
325 The temperature exceeds or
falls below the top or bottom
limit value 2.
x
Pressure regulator
326 No new measured values from
the analog/digital converter.
x x Notify service.
327 The measured value exceeds
the value range of the ana-
log/digital converter.
x x Notify service.
