No. Text S A
W
F Reaction/Comment
328 A calculation error occurred
while calculating the measured
value.
x x Notify service.
329 The pressure exceeds or falls
below the top or bottom limit
value 1.
x FID: Check supply gas pressures:
Output = instrument air,
Air = combustion air,
H2 = combustion gas.
330 The pressure exceeds or falls
below the top or bottom limit
value 2.
x
331 The position value of the pres-
sure is outside the valid area.
x x FID: Check supply gas pressures.
I/O devices
332 Loss of auxiliary current in the
I/O card.
x x The I/O card is faulty. Replace card.
333 An I/IO type that is not yet
available is configured.
x x Correct configuration with test and adjustment soft-
ware.
334 No new measured values from
the analog/digital converter.
x x The I/O card is faulty. Replace card.
335 The measured value exceeds
the value range of the ana-
log/digital converter.
x x Check signals on the analog inputs.
If OK, check configuration and adjustment of the analog
inputs.
336 A calculation error occurred
while calculating the measured
value.
x x Check configuration and adjustment of the analogies
and outputs.
337 Line break and analog output. x x Check lines in analog output.
338 Line break in digital input (hu-
midity sensor).
x x Check humidity sensor in the system cooler.
339 Line break or short-circuit in
the analog input.
x x Check temperature of the system cooler.
340 The value of the analog input
exceeds or falls below the top
or bottom limit value 1.
x Check temperature of the system cooler.
341 The value of the analog input
exceeds or falls below the top
or bottom limit value 2.
x Check temperature of the system cooler.
Flow monitor
342 The flow rate undershoots limit
value 1
x Check sample preparation.
Alarm value 1 = 25 % of MRS.
343 Flow rate undershoots limit
value 2.
x x Check sample preparation.
Alarm value 2 = 10 % of MRS.
Automatic calibration is interrupted and disabled
Measured value
344 The measured value exceeds
the value range of the measur-
ing range.
Measured value > +130% MRS; not in the logbook
345 The measured value falls below
the value range of the measur-
ing range.
Measured value < −100% MRS; not in the logbook
Flow controller
398 No new measured values from
the analog/digital converter.
x x Notify service.
