184 ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A
No. Text S A
W
F Reaction/Comment
399 The measured value exceeds
the value range of the ana-
log/digital converter.
x x Check measuring gas concentration. Check push con-
nections in the analyzer system Notify service.
400 A calculation error occurred
while calculating the measured
value.
x x Notify service.
401 The flow exceeds or falls below
the top or bottom limit value 1.
x Check measuring gas path. Notify service.
402 The flow exceeds or falls below
the top or bottom limit value 2.
x x Check measuring gas path. Notify service.
403 The position value of the flow
controller is outside the valid
area.
x x Notify service.
FID
411 The analyzer is in standby. Re-
activation in the menu: Service/
Test..Standby/Restart FID
x x Restart FID.
412 Ignition failed. The analyzer
needs to be reactivated manu-
ally. Reactivation in the menu:
Service/Test..Standby/Restart
FID
x x Check operating gases.
Restart FID.
413 Failure of auxiliary current in
the analyzer hardware.
x x Notify service.
414 The position value of this con-
troller is below the permissible
range. (< 20%)
x x Check operating gases and connection leads. Restart
FID, where applicable. Notify service.
415 The position value of this con-
troller is above the permissible
range. (> 90%)
x x
Adjustment
500 System bus communication
disrupted.
501 Required functionality is not
available in the system module.
Check software version of the analyzer module and carry
out update, if applicable.
502 A system error occurred in the
system module addressed.
Adjustment is canceled.
Notify service.
503 Amplification error during ad-
justment. Adjustment impossi-
ble.
x Adjustment is canceled.
End point gas concentration too low – check.
507 A combination of the following
errors has occurred: drift half,
drift, amplification of the delta
drift.
Adjust detector displayed manually at the zero point and
end point.
508 Unknown error number. Check
software versions.
Message during automatic adjustment. Check software
version of analyzer module and system controller.
509 Automatic adjustment started. for information
510 Automatic adjustment ended. for information
511 Automatic adjustment canceled
externally.
for information
