Advanced Navigation Boreas D90 - Simrad 3000 Output; Serial Port Passthrough; GNSS Receiver Passthrough

GPIO Port:
1
Auxiliary:
Transmit
Description:
This function outputs the Simrad 1000 format at a user configurable rate of up to 50 Hz.
The output rate can be configured using the page in the 9.1 Using the Web User
Interface.
10.6.1.45 Simrad 3000 Output
Type:
Serial Transmit
GPIO Port:
1
Auxiliary:
Transmit
Description:
This function outputs the Simrad 3000 format at a user configurable rate up to 50 Hz. The
output rate can be configured using the page in the 9.1 Using the Web User Interface.
10.6.1.46 Serial Port Passthrough
Type:
Serial
GPIO Port:
1, 2
Auxiliary:
All
Description
:
This function allows passthrough communication through either GPIO 1 and 2 or the
Auxiliary port. To transmit data use the 11.3.7 Serial Port Passthrough Packet. When
data is received it will be sent back using the same 11.3.7 Serial Port Passthrough
Packet.
10.6.1.47 GNSS Receiver Passthrough
Type:
Serial
GPIO Port:
1, 2
Auxiliary:
All
Description
:
This function allows for pass through connection to the internal GNSS receiver. This is
useful for firmware updates of the internal GNSS receiver.
v1.2 Page 108 11 Oct 2022
Boreas Reference Manual • Interfacing
