Specification Value
Environmental Protection MIL-STD-810H
IP67
Mean Time between Failure (MTBF) > 70,000 hours
Shock Limit 50 g 11 ms
Vibration Limit 8 g rms 20-2000 Hz random
Dimensions (height x width x length) 160 mm x 140 mm x 115.5 mm
Weight 2.5 kg
Table 13: Hardware Specifications for Boreas
6.2.1 Mechanical Drawings
Figure 4: Mechanical Drawings of Boreas
v1.2 Page 14 11 Oct 2022
Boreas Reference Manual • Specifications
