Advanced Navigation Boreas D90 - Table of Contents

Contents
1 Revision History 1
2 Introduction 2
2.1 Firmware Changelog 3
2.2 Hardware Changelog 3
3 Evaluation Kit 4
3.1 Evaluation Kit Contents 5
4 Getting Started 7
5 Part Numbers and Ordering 8
5.1 Evaluation Kit 8
5.2 Standalone Units 8
5.3 GNSS Receiver Licence Upgrades 9
5.4 Accessories 10
6 Specifications 11
6.1 Navigation Specifications 11
6.1.1 Dual Antenna Heading Accuracy 12
6.1.2 Sensor Specifications 12
6.1.3 GNSS Specifications 13
6.2 Hardware Specifications 13
6.2.1 Mechanical Drawings 14
6.2.1.1 Cable Bend Radius 15
6.2.2 Serial Number 15
6.3 Communication Specifications 16
6.4 Electrical Specifications 16
6.5 Ethernet Connection 18
6.6 IO Connection 18
6.6.1 IO Unterminated Cable 18
6.6.2 IOBreakout Cable 20
6.6.3 Custom IO Termination 22
7 Installing Boreas 23
7.1 Installation Checklist 23
7.2 Mounting Boreas 24
7.3 Mounting Alignment 26
7.4 Cable Bend Radius 27
7.5 MIL-DTL-38999 Series IIIConnector Mating 28
Page i
