Advanced Navigation Boreas D90 - Inactive; 1 PPS Output

Function Type Name
Serial Receive 10.6.1.28 NMEA Input
10.6.1.29 Novatel GNSS Input
10.6.1.30 Topcon GNSS Input
10.6.1.31 ANPP Input
10.6.1.32 RTCM Differential GNSS Corrections Input
10.6.1.33 Trimble GNSS Input
10.6.1.34 u-blox GNSS Input
10.6.1.35 Hemisphere GNSS Input
10.6.1.36 Teledyne DVL Input
10.6.1.37 Tritech USBL Input
10.6.1.38 Linkquest DVL Input
10.6.1.39 Linkquest USBL Input
10.6.1.40 Nortek DVL Input
Serial Transmit 10.6.1.41 NMEA Output
10.6.1.42 ANPP Output
10.6.1.43 TSS1 Output
10.6.1.44 Simrad 1000 Output
10.6.1.45 Simrad 3000 Output
Serial 10.6.1.46 Serial Port Passthrough
10.6.1.47 GNSS Receiver Passthrough
Table 33: Dynamic Pin Functions
10.6.1.1 Inactive
Type:
Tristate
GPIO Port:
1, 2
Auxiliary:
All
10.6.1.2 1PPS Output
Type:
Digital Output
GPIO Port:
1, 2
Auxiliary:
Transmit
Description
:
There is a difference between the output of the GPIO and auxiliary ports when set to
1PPS output mode.
v1.2 Page 97 11 Oct 2022
Boreas Reference Manual • Interfacing
