Figure 13: Bend Radius Using Advanced Navigation Supplied Cables
For space-constrained applications, it may be necessary to use single-insulated wires with a customer-supplied
plug.
See 7.8 GNSS Antennas for information about the bend radius of antenna cables.
7.5 MIL-DTL-38999 Series IIIConnector Mating
In order to maintain proper ingress protection, it is important that a proper connection is made to the MIL-DTL-
38999 Series IIIIO and Ethernet connectors.
Figure 14: Unmated Connector Figure 15: Correctly Mated Connector
