11.4.35 Wind Packet
This packet provides the Boreas current 2D wind velocity. These values are only valid when external air data is
provided to Boreas. This can be either through the 11.4.40 External Air Data Packet or when a pitot tube is
interfaced to one of the GPIO pins. When this packet is written to the device, it disables the wind estimation filter
and the wind values provided are used statically.
Wind Packet
Packet ID 57
Length 12
Read / Write Read / Write
Field # Bytes Offset Data Type Size Description
1 0 fp32 4 Wind velocity north (m/s)
2 4 fp32 4 Wind velocity east (m/s)
3 8 fp32 4 Wind velocity standard deviation (m/s)
Table 97: Wind Packet
11.4.36 Heave Packet
Heave Packet
Packet ID 58
Length 16
Read / Write Read
Field # Bytes Offset Data Type Size Description
1 0 fp32 4 Heave point 1 (m)
2 4 fp32 4 Heave point 2 (m)
3 8 fp32 4 Heave point 3 (m)
4 12 fp32 4 Heave point 4 (m)
Table 98: Heave Packet
11.4.37 Raw Satellite Data Packet
The Boreas Manager Log Converter will automatically convert this packet to RINEX 3.02 format.
Raw Satellite Data Packet
Packet ID 60
Length 16 + Satellites * (6 + Frequencies * 26)
Read / Write Read
Field # Bytes Offset Data Type Size Description
1 0 u32 4 Unix time (seconds)
2 4 u32 4 Nanoseconds
3 8 s32 4 Receiver clock offset (nanoseconds)
