Figure 28: Boreas Web UI Device Information Page
9.1.2.3 Subcomponent Information
The Subcomponent Information page shows the serial numbers and hardware version information for the
Boreas subcomponents. This will be useful information to include when contacting our support team.
9.1.2.4 Status
The Status page shows the current status of Boreas as reported by the System State packet (ID #20) and Raw
GNSSPacket (ID #29), detailed in sections 11.4.1 System State Packet and 11.4.10 Raw GNSS Packet.
Note: The following Status flags do not update for Boreas units with a Trimble BD992 GNSSReceiver.
These flags are only applicable to Aries GNSSReceivers:
GNSS 2
Antenna 1 disconnected
Antenna 2 disconnected
Antenna 1 short
Antenna 2 short
