11.3.8 IP Configuration Packet
IP Configuration Packet
Packet ID 11
Length 30
Read / Write Read / Write
Field # Bytes Offset Data Type Size Description
1 0 u8 1 Permanent
2 1 u8 1 11.3.8.1 DHCP Mode
3 2 u32 4 IP Address
4 6 u32 4 IP Netmask
5 10 u32 4 IP Gateway
6 14 u32 4 DNS Server
7 18 u32 4 Boreas Serial number part 1
8 22 u32 4 Boreas Serial number part 2
9 26 u32 4 Boreas Serial number part 3
Table 53: IP Configuration Packet
11.3.8.1 DHCP Mode
Bit Description
0 DHCP Enabled
1 Automatic DNS
2-4 Link Mode. See 11.3.8.2 Link Mode Index
5-7 Reserved (set to zero)
Table 54: DHCP Mode
11.3.8.2 Link Mode Index
Value Bit 4 Bit 3 Bit 2 Description
0 0 0 0 Auto
Table 55: Link Mode Index
11.3.8.3 Discovery Network Setting Overwrite
Settings 7,8 and 9 are optional over standard network interfaces but required to overwrite settings over multi-
cast discovery. To overwrite network settings for a device over multi- cast send this packet to address
239.48.81.7 port 48817, the serial number must be set to the serial number of the device you want to overwrite
settings for.
