Table 146: NMEA Fix Behaviour
11.5.10.4 Port Output Rates
Value Bit 3 Bit 2 Bit 1 Bit 0 Description
0 0 0 0 0 Disabled
1 0 0 0 1 0.1 Hz
2 0 0 1 0 0.2 Hz
3 0 0 1 1 0.5 Hz
4 0 1 0 0 1 Hz
5 0 1 0 1 2 Hz
6 0 1 1 0 5 Hz
7 0 1 1 1 10 Hz
8 1 0 0 0 25 Hz
9 1 0 0 1 50 Hz
Table 147: Port Output Rates
11.5.11 Dual Antenna Configuration Packet
By default the system uses automatic offset with primary front and secondary rear.
When using an automatic offset:
l
There are four available configurations, listed in the Automatic Offset Orientations table below.
l
Manual offset values will be ignored and should be set to zero.
l
The manual offset values will be populated with the automatically calculated offset values.
If your antenna configuration does not match one of the four available automatic offset configurations you must
use a manual offset. These values are measured from the secondary antenna to the primary antenna in the
body co-ordinate frame.
Dual Antenna Configuration Packet
Packet ID 196
Length 17
Read / Write Read / Write
Field # Bytes Offset Data Type Size Description
1 0 u8 1 Permanent
2 1 u16 2 Offset type
3 3 u8 1 Automatic offset orientation
4 4 u8 1 Reserved (set to zero)
5 5 fp32 4 Manual offset X (m)
v1.2 Page 170 11 Oct 2022
Boreas Reference Manual • Advanced Navigation Packet Protocol
