Part Number Quantity Description Notes
BOREAS-D90
or BOREAS-D90-
BD992
1 Boreas INS Unit Boreas unit in rugged enclosure with
Aries Dual GNSS Receiver or Trimble
BD992 GNSSReceiver
VSP6337L 2 VeroStar GNSSAntenna VeroStar GNSS Antenna - L1/L2/L5
plus L band, pole mount, TNC Female
Connector
BF046WS210224-
01
2 GNSS antenna cable TNC
to TNC 4 m
4 metre RG-58A/U antenna cable with
TNC connectors
CABLE-FTDI 1 RS232/422 Adaptor to
USB
FTDI USB to RS232 / RS422 (select-
able) 1 metre cable
CABLE-38999-
RJ45-3M
1 Ethernet MIL-DTL-38999
Series III RJ45 to RJ45 3
m
Ethernet cable 3 m industrial
MIL-DTL-38999 Series III RJF TV RJ45
male to RJ45 male
See 6.5 Ethernet Connection.
CABLE-38999-19-
32-BREAKOUT
1 Breakout cable for IO con-
nection
Breakout cable for IO connection 2 m
MIL-DTL-38999 Series III Size 19, 32-
pin connector
Connectors for Primary, Auxiliary, CAN,
GPIO, 1PPS, Alert and Power. See
6.6.2 IOBreakout Cable.
SUPPLY-24V 1 24 VDCpower supply 100-240 V AC Mains to 24 V DC Power
Supply (DC jack)
Includes 2-pin plug types A/C/G/I
38999-19-CAP 1 Waterproof cap for Size 19
MIL-DTL-38999 Series III
socket connector
Used to maintain IP67 rating when not
using an Ethernet connection
BOREAS90-KIT-
CASE
1 Boreas 90 Evaluation Kit
case
Rugged transport case
Table 4: Evaluation Kit Contents
