R3132 Series Spectrum Analyzer Operation Manual
3.3.4 CONFIG Key (Configuration)
3-23
3.3.4 CONFIG Key (Configuration)
This section describes the Config menu(1/2) displayed when the
CONFIG
key is pressed.
Pressing this key allows you to set a GPIB interface.
GPIB Sets the GPIB address for the analyzer.
RS232 Displays the RS232 dialog box.
Baud Rate Sets the transmission rate to 600, 1200, 2400, 4800, 9600 or
19200 bps.
Data Length Sets the data bit length to 7 or 8 bits.
Stop Bit Sets the stop bit to either 1 or 2.
Parity Bit Sets the parity bit type.
NONE: Does not perform parity checking.
ODD: Sets the parity bit type to odd.
EVEN: Sets the parity bit type to even.
Flow Control Turns the flow control function on.
NONE: No flow control is performed.
XON/XOFF:
Flow control is performed according to the XON or
XOFF code sent.
Copy Config Displays the Copy Config menu used to set the destination of
screen data output.
Printer Displays the Printer dialog box.
