R3132 Series Spectrum Analyzer Operation Manual
6.2 External Mixer OPT17
6-14
6.2 External Mixer OPT17
(1) Introduction
This chapter provides OPT3172/3182+17 external mixer performance verification test procedures,
item by item as listed on Table 6-3.
Performance verification will be carried out under following condition.
Temperature range: 20 °C to 30 °C
Relative Humidity: 85 % or less
Table 6-3 List of Performance Verification Test Items
(2) Test Equipment
Table 6-4 lists equipment for the performance verification test.
The equipment needed to perform all of the performance test.
Equipment lists for individual tests are provided in each performance verification test procedure.
Table 6-4 Equipment List for Performance Verification Test
No. Test Description Applicable Models
1 Noise Level OPT3172/3182+17
2 Frequency Response OPT3172/3182+17
No. Description
Critical Specifications
for substitute Model
Model
Recommended
Manufacturer Notes
1 Sweeper No substitute model
recommended
83640 Agilent
Technologies
SG
2 Soure Module No substitute model
recommended
83556A Agilent
Technologies
-
3 10 dB Fixed Attenuator No substitute model
recommended
521U MPI -
4 RF Power Sensor No substitute model
recommended
Q8486A Agilent
Technologies
-
5 RF Power Sensor No substitute model
recommended
V8486A Agilent
Technologies
6 RF Power Meter No substitute model
recommended
437B Agilent
Technologies
-
7 RF Cable Type: SMA(m)-SMA(m) DCP-FF00092X02 Advantest -
8 Spectrum Analyzer No substitute model
recommended
R3172/R3182 Advantest -
