R3132 Series Spectrum Analyzer Operation Manual
5.2.13 Image, Multiple and Out-of-Band Responses
5-50
Table 5-17 Image, Multiple, Out-of-Band Response Test Setting
Center Frequency Signal Generator Correction Frequency for Power Meter Note
2 GHz 1.9572 GHz 1.96 GHz
2 GHz 1.1572 GHz 1.16 GHz
2 GHz 10.5228 GHz 10.52 GHz
2 GHz 8.2614 GHz 8.26 GHz
5.5 GHz 6.3428 GHz 6.34 GHz For R3162
8 GHz 7.1572 GHz 7.16 GHz For R3162
8 GHz 3.7893 GHz 3.79 GHz For R3162
5.5 GHz 6.3428 GHz 6.34 GHz For R3172/82
5.5 GHz 11.4214 GHz 11.42 GHz For R3172/82
5.5 GHz 17.3428 GHz 17.34 GHz For R3172/82
5.5 GHz 23.2642 GHz 23.26 GHz For R3172/82
12 GHz 12.8428 GHz 12.84 GHz For R3172/82
12 GHz 5.7893 GHz 5.79 GHz For R3172/82
12 GHz 18.2107 GHz 18.21 GHz For R3172/82
12 GHz 24.4214 GHz 24.42 GHz For R3172/82
21 GHz 21.8428 GHz 21.84 GHz For R3172/82
21 GHz 6.71907 GHz 6.72 GHz For R3172/82
21 GHz 13.8595 GHz 13.86 GHz For R3172/82
24.4 GHz 25.2428 GHz 25.24 GHz For R3172/82
24.4 GHz 5.78395 GHz 5.78 GHz For R3172/82
24.4 GHz 11.9893 GHz 11.99 GHz For R3172/82
24.4 GHz 18.19465 GHz 18.19 GHz For R3172/82
28 GHz 28.8428 GHz 28.84 GHz For R3182
28 GHz 6.89465 GHz 6.89 GHz For R3182
28 GHz 13.7893 GHz 13.79 GHz For R3182
28 GHz 20.89465 GHz 20.89 GHz For R3182
35 GHz 35.8428 GHz 35.84 GHz For R3182
35 GHz 6.91572 GHz 6.92 GHz For R3182
35 GHz 11.5262 GHz 11.53 GHz For R3182
35 GHz 23.19287 GHz 23.19 GHz For R3182
