R3132 Series Spectrum Analyzer Operation Manual
2.1 Panel Description
2-1
2 OPERATION
This chapter describes the following:
• Front and rear panel controls and connectors
• Screen annotation
• Basic operation
• Measurement examples
• Expanded functions
2.1 Panel Description
2.1.1 Front Panel
This section contains detailed views of the front panel and explanations for the panel keys or connectors
shown in those views Figure 2-1 shows the front panel location of the nine detail views.
Figure 2-1 Front Panel (R3132/32N/62)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
To Next Page
