R3132 Series Spectrum Analyzer Operation Manual
2.2.15 External Mixer (OPT16 thru OPT19)
2-54
Loading frequency correction data
This operation loads frequency correction data and setting conditions from a floppy
disk compatible with the external mixer being used.
6. Press RECALL and Device RAM/FD(FD).
7. Select a file to be opened from the file list using the data knob. The relationships
between the frequency ranges (of the external mixer being used) and the file
names are shown below.
Table 2-3 File Names
8. Press Recall.
Frequency correction data is automatically loaded and External Mixer Mode is
automatically set.
OPT No. Frequency range External mixer used File names
OPT16 26.5 to 40 GHz WHMB-28S WHMB28
OPT17 40 to 60 GHz WHMB-19S WHMB19
OPT18 50 to 75 GHz WHMB-15S WHMB15-1
70 to 80 GHz WHMB15-2
OPT19 75 to 110 GHz WHMB-10S WHMB10
