R3132 Series Spectrum Analyzer Operation Manual
5.2.17 Frequency Span Accuracy
5-71
Table 5-22 Center and Span Frequencies for the R3172/82
Following steps are applied for R3182
Measurement for a center frequency of 20 GHz, 28 GHz and 35 GHz.
15. Repeat steps 3 through 11 for each frequency setting listed in Table 5-23.
Table 5-23 Center and Span Frequencies for the R3182
Center
Frequency
Frequency Span
SMP04
1st Frequency
SMP04
2nd Frequency
10 GHz 10 MHz 9.996 GHz 10.004 GHz
10 GHz 100 MHz 9.96 GHz 10.04 GHz
10 GHz 1 GHz 9.6 GHz 10.4 GHz
10 GHz 10 GHz 6 GHz 14 GHz
10 GHz 20 GHz 1 GHz 19 GHz
17 GHz 10 MHz 16.996 GHz 17.004 GHz
17 GHz 100 MHz 16.96 GHz 17.04 GHz
17 GHz 1 GHz 16.6 GHz 17.4 GHz
Center
Frequency
Frequency Span
SMP04
1st Frequency
SMP04
2nd Frequency
28 GHz 10 MHz 27.996 GHz 28.004 GHz
28 GHz 100 MHz 27.96 GHz 28.04 GHz
28 GHz 1 GHz 27.6 GHz 28.4 GHz
35 GHz 10 MHz 34.996 GHz 35.004 GHz
35 GHz 100 MHz 34.96 GHz 35.04 GHz
35 GHz 1 GHz 34.6 GHz 35.4 GHz
20 GHz 30 GHz 8 GHz 32 GHz
