ADVANTEST R3162

R3132 Series Spectrum Analyzer Operation Manual
5.2.17 Frequency Span Accuracy
5-70
Table 5-20 Center and Span Frequencies for the R3132 series
Following steps are applied for R3162/72/82
Measurement for a center frequency of 4 GHz
13. Repeat steps 3 through 11 for each frequency setting listed in Table 5-21.
Table 5-21 Center and Span Frequencies for the R3162/72/82
Following steps are applied for R3172/82
Measurement for a center frequency of 10 GHz and 17 GHz
14. Repeat steps 3 through 11 for each frequency setting listed in Table 5-22.
Center
Frequency
Frequency Span
SMP04 1st
Frequency
SMP04 2nd
Frequency
1.5 GHz 1 MHz 1.4996 GHz 1.5004 GHz
1.5 GHz 10 MHz 1.496 GHz 1.504 GHz
1.5 GHz 100 MHz 1.46 GHz 1.54 GHz
1.5 GHz 1 GHz 1.1 GHz 1.9 GHz
1.5 GHz 3 GHz 0.1 GHz 2.9 GHz
Center
Frequency
Frequency Span
SMP04 1st
Frequency
SMP04 2nd
Frequency
4 GHz 10 MHz 3.996 GHz 4.004 GHz
4 GHz 100 MHz 3.96 GHz 4.04 GHz
4 GHz 1 GHz 3.6 GHz 4.4 GHz
4 GHz 8 GHz 0.2 GHz 7.2 GHz
7.5 GHz 10 MHz 7.496 GHz 7.504 GHz
7.5 GHz 100 MHz 7.46 GHz 7.54 GHz
