R3132 Series Spectrum Analyzer Operation Manual
3.4 List of Settings
3-85
3.4 List of Settings
3.4.1 Factory Defaults
The table below lists the factory defaults (for both the analyzer parameters and settings). These values are
used when the
SHIFT
and
CONFIG(PRESET)
keys are pressed.
Table 3-1 Factory Defaults (R3132/N)
Parameter Factory defaults
Center frequency 1.5GHz
Frequency span 3GHz
Reference level 0dBm (R3132),
108.8dBµV (R3132N)
Sweep time AUTO 20ms
Resolution bandwidth (RBW) AUTO 3MHz
Video bandwidth (VBW) AUTO 3MHz
Input attenuator AUTO 10dB
Trigger mode Free Run
Trace mode A Write B Blank
Detector mode A Normal B Normal
Marker OFF
Line OFF
Window OFF
Title function OFF
Vertical graduation 10dB/div
