R3132 Series Spectrum Analyzer Operation Manual
4.2.9 GPIB Command Codes
4-32
Table 4-9 MKR (1 of 2)
(*1):When using the delta mode, the frequency or level difference is used.
Function Listener Code
Talker Request
Code Output Format
Marker ON
OFF
MN * (*1)
MKOFF
MO
MN? 0: OFF
1: Normal
2: Delta
Normal Marker
(∆Marker OFF)
MK *
MKN *
–––
–––
–––
–––
∆Marker ON MKD * ––– –––
Marker frequency ––– MF? Frequency (Time)(*1)
Marker Level ––– ML? Level(*1)
Frequency + Level ––– MFL? Frequency (Time), Level(*1)
Normal marker absolute value
Frequency
Level
–––
–––
MDF1?
MDL1?
Normal MKR frequency
Normal MKR level
∆Marker absolute value
Frequency
Level
–––
–––
MDF2?
MDL2?
Delta MKR frequency
Delta MKR level
Fixed∆Marker
ON
OFF
FX ON
FX OFF
FX? 0:OFF
1:ON
MKR step Size MPM * MPM? Frequency (Time)
MKR step auto MPA MPA? 0:Manual
1:Auto
Signal Track
ON
OFF
SG ON
SG OFF
SG? 0:OFF
1:ON
MKR CoupleON
OFF
CPLMK [ON]
CPLMK OFF
CPLMK? 0:OFF
1:ON
MKR move A Trace
B Trace
MKTRACE TRA
MKTRACE TRB
MKTRACE? 0:Blank
1:A Trace
2:B Trace
Peak Search PS ––– –––
Next Peak
Next Peak Left
Next Peak Right
NXP
NXL
NXR
–––
–––
–––
–––
–––
–––
Min Search MIS ––– –––
Max-Min Search MMS ––– –––
Continuous Peak?
ON
OFF
CP ON
CP OFF
CP? 0:OFF
1:ON
